General purpose 2
code : 1901-KBNI010-500
| REFERANCE: | 1811-ABNF016-250-220AC |
| MAIN SERIES: | General Purpose - Low Differential Pressure |
| FUNCTION: | 2/2 Ways |
| POSITION: | Normally Open |
| OPERATION TYPE: | Pilot Operating |
| SEAT SEAL MATERIAL: | NBR Diaphragm / NBR Seal |
| PORT SIZE: | 1” |
| ORIFICE: | 25mm |
| Kv: | 150.00 l/min |
| Pmin-Pmax (bar): | 0,1-16 bar |
| Tmin / Tmax (°C): | -10 °C / 80 °C |
| WEIGHT: | 1.060 Kg |
| COIL VOLTAGE - TOLERANCE: | 12,24,220,230V AC/DC |
